Massoth Product List Massoth Sound Decoders Massoth XLS On-board Sound Decoder


Massoth eMOTION XLS On-board Sound Decoder

Product number: 82X6XXX
$229.00 plus shipping

In stock for immediate delivery
Please contact us to order

eMotion XLS On-board Sound Decoder

The Massoth eMOTION XLS on-board decoder is a powerful 4.0 Amps driving, function, and sound decoder designed for installation in LGB locomotives factory equipped with an LGB DCC Interface or an LGB On-board Decoder. Installation is plug and play, existing cables are unplugged from the factory installed PCB and plugged into the Massoth on-board decoder.

The XLS on-board decoder features a 3.5Amps output stage for up to two motors, 3 light outputs, 4 function outputs, 2 contacts inputs, a SUSI-MTB(Märklin Train Bus) interface, and an integrated 2.8 watt Class D sound amplifier with 6 independent sound channels.

The XLS offers selectable 14/28/128 speed steps, analog and digital operation, digital/analog Back EMF, and overload - overheat protection for motor and function outputs.

The Massoth eMOTION XLS-M1 decoder is fully compatible with NMRA/DCC, and compatible with all generations of the LGB® MTS system.

Operating the XLS decoder with an additional power buffer increases its dependability: brief track power disruptions are bridged in analog and digital operation and contaminated tracks and switch frogs are negotiated without any speed changes or interruptions.

Summary of Features:

  • Total amperage: 4.0Amps
  • Motor amperage: 3.5AMps
  • Light and function outputs amperage: 1.2Amps
  • Compatible with NMRA DCC and all generations of LGB® MTS systems
  • Serial and parallel control of all lights and function outputs, including LBG® P-sound updates
  • Digital and analog operation with automatic recognition
  • 10239 Locomotive addresses
  • 14/28/128 speed steps
  • 256 internal speed steps
  • Programmable speed curve
  • Adjustable starting, mid, and maximum speed
  • Adjustable acceleration and deceleration time
  • Adjustable motor frequency (90Hz-16kHz)
  • Latest load control technology, Back-EMF, analog and digital
  • Switching speed activated with mappable function key
  • 3 light outputs, 3 x 300mAmps (front, interior, and rear)
  • 4 function outputs, 2 x 600mAmps (F1-F2), 2 X 10mAmps (F3-F4)
  • 2 Reed contact inputs
  • 1 Automatic uncoupler connection
  • Connection for optional power buffer
  • Connection for programmable pulse generation function
  • 2 Clock/hall effect sensor connections
  • Massoth-SUSI interface
  • Light and function outputs dimmable; can be activated in analog operation
  • Programmable pulse generator function
  • Easy to use function mapping
  • Free command allocation of all function outputs (F1-F16)
  • Rest function for all CV values
  • Overload protection for function outputs
  • Overheat protection for function outputs
  • Sounds and firmware updatable

Sound Features:

  • 2.8 watts Class D amplifier for 8 Ohms speaker
  • 6 channel play-back (6 sounds at the same time)
  • Memory capacity for max. 200 sec. of recorded sound
  • play-back frequency: 10Hz-16KHz
  • Volume control by potentiometer or CV programming (also individual sounds)
  • Sound functions usable in analogue mode

Technical specifications

  • Power supply: 0-24 Volts DC/DCC
  • Maximum total load: 4.0Amps
  • Motor output: Max. 3.5Amps, 70Hz-16kHz, load controlled, digital and analog
  • Light outputs: Max.(3 X 300mAmps) dimmable
  • Function outputs:(4 X 600mAmps), (4 X 10mA)
  • Total light and function outputs combined: Max. 1.3Amps
  • Loudspeaker 8 Ohms (Min. 1.5 watts)
  • Temperature range: -4°F to 113°F
  • Dimensions: 60x32 x18 mm

Scope of Delivery

  • eMOTION XLS On-board Sound Decoder
  • One Loudspeaker (see listing below)
  • 2 sets of LGB® motor-block connecting cables (4 pieces each)
  • 2 screws 2.9x13 mm
  • 2 screws 2.9X19mm
  • User's Manual
  • Configuration Manual

Adobe Thumbnail
User's manual

Adobe Thumbnail
Configuration Manual

Adobe Thumbnail
Recommended Speakers

Massoth eMOTION XLS On-board Decoder sound options

The XLS decoders are programmed at the factory with one of the locomotive sounds listed below. At any given time, we may not have in stock a factory programmed decoder with the sound you want. We can re-program any XLS decoder we have in stock with the specific sound you want, at no extra charge.

To view the sound data sheet for a specific decoder, click on the corresponding reference number. To view the picture of the prototype locomotive, click on the locomotive's name. To listen to a sample of how the decoder reproduces the sounds of a specific locomotive, click on the corresponding speaker icon.

The music you hear in the background of the sample is for copy protection only; you will not hear it when listening to an actual decoder.

Availability status legend
not in production Not in production, not available
New Item, available shortly New Item, available shortly
available Available, in stock
available Available, in very short supply
not available Currently unavailable, out of stock

Reference Number Availability Status Prototype Locomotive's Name and Picture MP3
Steam Locomotives
8216014 item available Industrial field railway steam locomotive speaker
8216015 item available Tender for steam locomotive
8216018 item available Franzburg steam locomotive
8216019 item available US steam locomotive, 2-6-0 Mogul speaker
8216021 item available Stainz steam locomotive speaker
8216025 item available US steam locomotive Forney/Columbus speaker
8216026 item available HF 110 Rail Nicki & Frank S steam locomotive speaker
8216027 item available G 3/4 RhB Heidi steam locomotive speaker
8216047 item available HG 3/3 Ballenburg cog wheel steam Locomotive speaker
8216050 item available Kastendampflok, Feuriger Elias steam locomotive speaker
8216071 item available Baureihe U, Zillertalbahn steam locomotive speaker
8216074 item available 1C 99-5633 Spreewald steam locomotive speaker
8216080 item available 1C1 99-6001 HSB 2-6-2 steam locomotive speaker
8216081 item available 1E1 99-222 HSB 2-10-2 steam locomotive speaker
8216084 item available Saxonian IV K steam locomotive speaker
8216085 item available DR Mallet steam locomotive speaker
8216087 item available Mikado steam locomotive speaker
8216088 item available Uintah Mallet steam locomotive speaker
8216098 item available Saxonian I K steam locomotive speaker
8216099 item available Saxonian II K steam locomotive
8216110 item available 99 5901 HSB Mallet steam locomotive speaker
8216120 item available Fiffi + Pfiffi HSB steam locomotive speaker
8216200 item available G 4/5 RhB steam locomotive speaker
8216210 item available G 3/4 RhB Rhätia steam locomotive speaker
8216300 item available US Steam locomotive, Shay speaker
8216310 item available US Steam locomotive, K27/K28
8216500 item available BR 01 / 03 / 012 steam locomotive speaker
8216510 item available BR 80 steam locomotive speaker
8216520 item available SNCF Mikado steam locomotive speaker
8216530 item available BR 64 steam locomotive speaker
8216540 item available BR 24 steam locomotive
8216800 item available 99 4633 RüKB Rügen steam locomotive speaker
Diesel Locomotives
8226041 item available Tm 2/2 15ff RhB diesel tractor speaker
8226049 item available US diesel Locomotive GE P42 Genesis, AMD 103 speaker
8226051 item available V51 Rügen / V52 DB diesel locomotive speaker
8226052 Item Available 2091 ÖBB diesel locomotive speaker
8226055 item available US diesel locomotive, ALCO DL535E speaker
8226057 item available US diesel locomotive, EMD F7A/B speaker
8226059 item available HF 130 diesel locomotive speaker
8226063 item available LGB US diesel switcher
8226066 item available VT133 Anteater rail bus speaker
8226090 item available Köf diesel switcher speaker
8226091 item available Industrial field railway diesel switcher speaker
8226093 item available 199 012 HSB Köf diesel switcher speaker
8226096 item available 2095 ÖBB diesel locomotive speaker
8226110 item available T3 diesel rail car speaker
8226120 item available V3 diesel locomotive speaker
8226130 item available T1 diesel rail car
8226300 item available US diesel locomotive, EMD GP9
8226500 item available V200 (BR 220) BoBo big diesel locomotive speaker
8226510 item available V160 (BR 218) DB diesel locomotive speaker
8226520 item available VT98 rail car speaker
8226530 item available V60 diesel locomotive speaker
8226540 item available VW Bulli
8226550 item available V100 (BR 199 - BR 204) Harzkamel diesel locomotive speaker
8226560 item available Köf DB diesel switcher speaker
8226570 item available VT11.5 TEE DB diesel speaker
8226580 item available X5800 diesel rail bus
8226590 item available T478 diesel locomotive
8226600 item available V36 diesel locomotive
8226610 item available BR 132 Ludmilla
Electric Locomotives
8236022 item available ABe 8/12 RhB Allegra speaker
8236031 item available BR 101 DB speaker
8236035 item available Historic street car, (Darmstadt -Germany) speaker
8236038 item available New Orleans street car speaker
8236039 item available ABe 4/4 RhB rail car speaker
8236040 item available Ge 6/6 I RhB Crocodile speaker
8236042 item available Ge 4/4 III RhB
8236043 item available Ge 4/4 II RhB speaker
8236045 item available Ge 2/4 RhB speaker
8236075 item available E 10 (BR 110) DB Electric Locomotive speaker
8236200 item available Ge 6/6 II RhB speaker
8236210 item available Gem 4/4 I RhB speaker
8236220 item available Ge 4/4 RhB speaker
8236230 item available Ge 4/4 RhB Bernina Crocodile speaker
8236250 item available Ge 4/4 III MOB
8236260 item available Ge 4/4 III (incl. 100 Year Albula jubilee sound) speaker
8236510 item available BR 182 Taurus speaker
8236530 item available BR 194 (E 194) DB Crocodile speaker
